Bergamont E-Horizon FS Elite Speed
Model : 280983
Key Features
- Perfectly tuned Suntour suspension
- Shimano XT/Deore 1x12 drive train with wide gear range
- Magura MT5e/MT4e hydraulic disc brake
- Ergonomic contact points: Syncros Trekking saddle, Ergon GP10 lock-on grips
- Powerful LED lighting system by Busch + Müller with rear brake light function for added safety
- Bosch Gen. 4 Performance Line Speed Drive Unit
- Bosch 625 Wh integrated battery
- Bosch Kiox on-board computer offers more connectivity features
1. Size
This product is not available for purchase online. Please check with your local dealer or send us a message using our Contact Form.
Find a dealer
£5,049.00
SPECIFICATIONS
-
The benchmark in comfort, ergonomics, handling and safety, with full suspension 100/80 mm chassis and state of the art Bosch drive unit and PowerTube battery technology. Speed Pedelec (-45km/h) version.
condition of usage 2 -
Frame
28", ultra lite AL-6061 tubing, PowerTube battery, 80 mm rear travel -
Fork
Suntour Mobie 45 Air, RLR DS, 100 mm, 15x100 mm axle -
Rear Shock
Suntour UNAir R8, 80 mm, lockout -
Drive Unit
Bosch Performance Line Speed, Gen. 4, 250 W, 36 V, max. 45 km/h
-
Battery
Bosch PowerTube, 36 V Li Ion, 625 Wh -
Display
Bosch Kiox -
Rear Derailleur
Shimano Deore XT, RD-M8100, Shadow Plus -
Shifters
Shimano Deore, SL-M6100, 1x12-speed, rapidfire plus-shifter -
Crankset
FSA CK-320, 42t -
BB-Set
Bosch, Isis -
Chain
KMC e12S -
Cassette
Shimano Deore, CS-M6100, 10-51t -
Brake Levers
Magura MT, 3-fingers, ball-end, with brakelight switch -
Brakes
Magura MT5e (front) / Magura MT4e (rear), hydraulic disc brake -
Rotor
Magura Storm CL, 203 mm / Magura Storm CL, 180 mm -
Handlebar
BGM Pro, riserbar, backsweep: 15°, rise: 5 mm -
H'stem
BGM E-Bike, adjustable, for Kiox integration -
Seatpost
BGM Pro -
Seat
Syncros Capilano Trekking, gel -
Headset
FSA NO.57SC-1, A-Headset, semi-integrated, tapered -
Hub (Front)
Shimano HB-MT400, centerlock, disc, 15x100 mm axle -
Hub (Rear)
Shimano FH-MT410-B, centerlock, disc, 12x148 mm axle -
Spokes
Sapim Leader -
Rims
Ryde Rival 23 disc, eyelets -
Front Tire
Schwalbe Hurricane, Addix, reflective stripe, 57-622
Tube: Schwalbe AV19 -
Rear Tire
Schwalbe Hurricane, Addix, reflective stripe, 57-622
Tube: Schwalbe AV19 -
Lights
Front: B&M IQ-X-E, 150 Lux, LED
Rear: B&M LED, with brakelight -
Rack & Fenders
Fender: Racktime Alumee
Carrier: Racktime / BGM, Snapit 2.0 System -
Pedals
Syncros Trekking alloy -
Accessories
Kickstand: Syncros -
Approx weight in KG
26,2 -
Color
flaky silver (matt) -
Frame size
46/50/54/58 cm -
Grips
Ergon GP10 -
Max. System Weight
140,0 kg
The overall weight includes the bike, the rider, the equipment and possible additional luggage.
Use
No Radar Chart Available Currently
Geometry
Technologies
Segmented Fender Solution
To allow a full range of movement for the suspension frame we designed a special part which enables us to cut the fender above the main frame while retaining its protective function. At the same time this part functions as a cable guide. Protecting and routing the cables to the rear end of the frame.
Universal Chassis Concept
We always made an extra effort when creating frame geometries and features to achieve superior riding capabilities. Using this knowledge we created a universal e-bike frame platform that perfectly integrates modern batteries and drive units. Using the same basic construction throughout our range means making premium features available on almost any level.
Level Load Solution
The carrier solution for our fullsuspension E-Trekking bikes is designed to stay almost level through the entire range of travel, by describing a near vertical path. This not only looks good but keeps your luggage more stable.Athlete
